GE® "S" Series 15.6 Cu. Ft. Top-Mount No-Frost Refrigerator

Model #: TBX16SSBRAA
Energy Guide
  • 15.6 cu. ft. capacity (Fresh Food 11.69 cu. ft. / Freezer 3.86 cu. ft.)
  • Classic white fruit / vegetable crispers
  • 2 adjustable, full-width wire everwhite fresh food cabinet shelves
  • Dimensions: 64 1/2 H x 28 W x 29 9/16 D
Learn More >
Dimensions: 64 1/2 H x 28 W x 29 9/16 D

Will this filter fit my refrigerator? reset search

Our water filter finder will guide you to the right filter for your refrigerator

✔This filter is match for your refrigerator

✗ This filter is not a match for your refrigerator

Need help finding your model number?
Loading Store Finder

Frequently Bought Together:

For personalized shopping help, call us at 1-800-430-1757

Complete Your Laundry Pair:

Matching Item



=
Price For Laundry Pair:
* Available in Select Zip Codes
  • 2 adjustable, full-width wire everwhite fresh food cabinet shelves

    2 adjustable, full-width wire everwhite fresh food cabinet shelves

    undefined

  • 2 fresh food door shelves with tall bottle storage

    2 fresh food door shelves with tall bottle storage

    undefined

  • Color-matched deluxe door handles

    Color-matched deluxe door handles

    undefined

  • 15.6 cu. ft. capacity (Fresh Food 11.69 cu. ft. / Freezer 3.86 cu. ft.)

  • Classic white fruit / vegetable crispers

  • Dairy compartment

  • 2 freezer door shelves

  • Galvanized steel case and doors

  • Ice tray shelf with 2 Ice 'N Easy trays

  • Equipped for optional automatic icemaker

See All Features

Dimensions: 64 1/2 H x 28 W x 29 9/16 D

APPEARANCE

Adjustable Rollers Yes
Coil-Free Back Yes
Door Stops Yes
Door Swing Reversible Hinges
Handle Color-Matched Deluxe
Textured Steel Case Galvanized

CAPACITY

Freezer Capacity 3.86 cu ft
Fresh Food Capacity 12.58 cu ft
Shelf Area 17.50 sq ft
Total Capacity (cubic feet) 15.60 cu ft

ECONOMICAL / QUIET

Cabinet Insulation Foam
Cabinet Liner ABS
Door Insulation Foam

FEATURES

Door Liner ABS
Exterior Style Free-Standing
Freezer Cabinet Shelf Features 1 Ice Tray Shelf
Freezer Door Shelves 2 Total
Freezer Features 2 Ice N' Easy Trays
Fresh Food Cabinet Shelf Features 2 Full-Width Adjustable
Wire
Fresh Food Cabinet Shelves 2
Fresh Food Door Shelves 2 w/Tall Bottle Storage
Fresh Food Features Dairy Compartment
Icemaker Non-Icemaker
Interior Lighting Yes
Vegetable / Fruit Crisper(s) 2

POWER / RATINGS

Volts/Hertz/Amps 120v; 60Hz; 15A

WARRANTY

Labor Warranty Limited 1-year entire appliance
Limited 5-year sealed refrigerating system
Parts Warranty Limited 5-year sealed refrigerating system
Warranty Notes See written warranty for full details

WEIGHTS & DIMENSIONS

Approximate Shipping Weight 172 lb
Back Air Clearances 1 in
Case Depth Without Door 26 in
Depth with Door Open 90° 54 1/2 in
Depth Without Handle 28 in
Height to Top of Case 64 in
Net Weight 155 lb
Overall Depth 29 9/16 in
Overall Height 64 1/2 in
Overall Width 28 in
Side Air Clearances 3/4 in
Top Air Clearances 1 in
Width w/Door Open 90 Degrees Less Handle 29 3/4 in
See All Specifications

Owners Manual

Schedule Service

Our online tools are here 24 hours a day to help you arrange the service you need.

Schedule Service

Do You Own This Product?

We're happy to help answer your questions.

Maintenance & Care for TBX16SSBRAA
