GE Zoneline® Premium Series Heat Pump Unit

Model #: AZ52H15DAD
previous image
next image
1/5
  • Decorative warm gray-beige front
  • Cooling with electric heat
  • 230/208 Volt outlet type
  • Dimensions: 16 H x 42 W x 13 3/4 D
Learn More >
Dimensions: 16 H x 42 W x 13 3/4 D

Will this filter fit my refrigerator? reset search

Our water filter finder will guide you to the right filter for your refrigerator

✔This filter is match for your refrigerator

✗ This filter is not a match for your refrigerator

Need help finding your model number?
Loading Store Finder

Frequently Bought Together:

For personalized shopping help, call us at 1-800-430-1757

Use & Care Manual View More

Complete Your Laundry Pair:

Current Item
GE Zoneline® Premium Series Heat Pump Unit
Model#: AZ52H15DAD
Clearance $1,149.00
+
Matching Item



=
Price For Laundry Pair:
* Available in Select Zip Codes

About This Product

  • Remote control compatibility for wall-mounted thermostats

    Remote control compatibility for wall-mounted thermostats

    undefined

  • Decorative warm gray-beige front

  • Cooling with electric heat

  • 230/208 Volt outlet type

  • Available in 14,700 / 14,400 BTU

  • Up to 10.0 EER, up to 3.1 COP

  • Electronic microprocessor controls

  • Factory-installed internal condensate removal system

  • Electronic 7-step temperature limiting to prevent overcooling or overheating of room

  • Staged heating

  • Freeze Sentinel protects unoccupied rooms against freeze-up

  • Hidden fan cycle switch

  • Hidden manual vent control for fresh air introduction

  • Reverse cycle defrost by monitoring operating conditions

  • Simultaneous supplemental heat allows unit to decide if BOTH heat pump and electric heat are needed for desired room temperature

See All Features

Claims & Certifications

Specs & Details

Dimensions: 16 H x 42 W x 13 3/4 D

ACCESSORIES

External Drain Kit RAD10 - Optional
Insulated Wall Case RAB71A
SMC Wall Case RAB77A4

CAPACITY

CFM Indoor Fan High 350
CFM Indoor Fan Low 330
Cooling BTUH (MAX) 14,700 Btu
Cooling BTUH (MIN) 14,400 Btu
Cooling EER (BTUH / Watt) 10.0/10.0
Dehumidification (pts./hr.) 4.8
Heating - Reverse Cycle - BTUH 13400/13200
Vent CFM (high fan at zero ESP) 70/65

FEATURES

Auto Frost Control Monitor Yes
Auto Power Recovery Yes
Central Desk Control Compatibility Yes
Electronic Micro Computer Control Yes
Fan Cycle Switch Hidden
Freeze Sentinel Yes
Heat Pump Yes
Louver Style Reversible
Manual Vent Control Yes
Multi-Directional Air Outlet Yes
Power Factor 95
Remote Control Yes
Rotary Compressor Yes
Sensible Heat Ratio at 230 Volts 65%
Solid State Thermostat Control Yes
Temperature Limiting Electronic 7-Step
Upfront Filter Yes

POWER / RATINGS

Cooling - Amperes 6.7/7.3
Cooling - Amperes; F.L. - Cooling 6.7/7.3
Cooling - Amperes; L.R. 38.0
Cooling - Watts 1470/1440
Voltage (MAX) 230 V
Voltage (MIN) 208 V

WARRANTY

Labor Warranty Limited 1-year entire appliance
Parts Warranty Limited 1-year entire appliance
Limited 5-year specified internal components
Warranty Notes See written warranty for full details

WEIGHTS & DIMENSIONS

Approximate Shipping Weight 144 lb
Net Weight 129 lb
Overall Depth 13 3/4 in
Overall Height 16 in
Overall Width 42 in
See All Specifications
