Universal 30" Telescopic Downdraft System

Model #: UVD6301SPSS
previous image
next image
1/5
Sale Clearance $1,241.00
$1,379.00
Save $138.00 (11%)
Save $15 ON A 3-PACK
  • 500 CFM Exhaust Fan
  • Adjustable Fan Speed
  • Kitchen Exhaust Fan Filters
  • Dimensions: 7 H x 30 W x 7 D
Learn More >

Color: Stainless Steel

Dimensions: 7 H x 30 W x 7 D

Will this filter fit my refrigerator? reset search

Our water filter finder will guide you to the right filter for your refrigerator

✔This filter is match for your refrigerator

✗ This filter is not a match for your refrigerator

Need help finding your model number?
Loading Store Finder

Frequently Bought Together:

For personalized shopping help, call us at 1-800-430-1757

Use & Care Manual View More

Complete Your Laundry Pair:

Current Item
Universal 30" Telescopic Downdraft System
Model#: UVD6301SPSS
Sale Clearance $1,241.00
$1,379.00
Save $138.00 (11%)
+
Matching Item



=
Price For Laundry Pair:
* Available in Select Zip Codes

About This Product

    • 500 CFM Exhaust Fan

      Efficiently remove smoke, grease, odors and moisture from the air thanks to a downdraft kitchen exhaust vent with a 500-CFM venting system

    • Adjustable Fan Speed

      Adjust your ventilation with the turn of a knob thanks to a kitchen exhaust fan that can be set to any speed between 0-500 CFM, depending on what you're cooking

    • Kitchen Exhaust Fan Filters

      Minimize clean-up and prevent unpleasant kitchen odor with a removable grease filter that helps cut down on scrubbing

    • Aluminum Mesh Filters

      Cut down on clean up thanks to mesh filters that are quick and easy to remove and are completely dishwasher safe

    • Hidden Design

      Streamline the look of your kitchen with a downdraft range vent that raises over the cooktop surface when needed and then retracts when not in use

    See All Features

    Claims & Certifications

    Specs & Details

    Dimensions: 7 H x 30 W x 7 D

    ACCESSORIES

    Duct Extension 100 ft.

    APPEARANCE

    Color Appearance Stainless Steel

    ECONOMICAL / QUIET

    Venting Type Externally Vented

    FEATURES

    CFM/ Sones Rating 500/11.0
    Control Type Rotary-Mechanical
    Cover Plate Stainless Steel
    Downdraft Exhaust (CFM) 500
    Exhaust Options Downdraft
    3-1/4" x 10" Rectangular Duct
    Vented to Outside
    Fan Speed Control Variable
    Max CFM 500
    Optional Blower Mount Capabilities Yes
    Product Type Telescopic Downdraft
    Removable Grease Filter(s) Yes
    Mesh
    Telescopic Assembly Stainless Steel

    POWER / RATINGS

    Amp Rating at 120V 4.0
    Electrical Requirements 120V ; 60Hz ; 4.0A
    Hertz 60
    Watts 375

    WARRANTY

    Labor Warranty Limited 1-year entire appliance
    Parts Warranty Limited 1-year entire appliance
    Warranty Notes See written warranty for full details

    WEIGHTS & DIMENSIONS

    Approximate Shipping Weight 67 lb
    Cabinet Width 30 in
    Net Weight 63 lb
    Overall Depth 7 in
    Overall Height 7 in
    Overall Width 30 in
    Telescoping Height 7 in
    See All Specifications
